Carry200 Portable AC Power Bank
Carry200 Slim Designed Portable Power Station 200wh with AC Pure Sine Wave outputs, USB outputs, DC outputs
Features:
- Carry200 is with a built-in pure sine wave inverter, which means it produces an output that is exactly the same as supplied by an AC wall outlet.
- Highly compacted design with e-vehicle lithium-ion battery pack, portable and powerful.?
- Safety priority, built-in BMS and protection circuit.
- Long service life for 5 years.
- Provide AC output and DC output two different output modes to match the demand for different electronic products.
- Apply USB 5V, DC 12V and AC power to the home appliance(less than rated power 120W) and portable electronics.
- The portable solar power generator Carry200 can be used as both an on-line UPS power supply and an outdoor emergency standby power supply.
Carry200 Slim Designed Portable Power Station 200wh with AC Pure Sine Wave outputs, USB outputs, DC outputs
Product Parameters:
| Model | Carry200 | |
| Battery Pack | Battery Cell | Lithium-ion INR18650P |
| Capacity | 11.1V 18AH(200Wh) | |
| Service Life | >800 cycles | |
| BMS(Battery Management System) | Multiple Safety Protection: overload, over-voltage, over-current, over-temperature, short circuit. | |
| DC Output | USB/USB QC3.0 | 1*5V 1.5A;1*5V2.4A; |
| Type-C USB | 1*Type C PD45W | |
| 12V DC | 1*12V/10A | |
| Efficiency | >93% at 70% of full loading | |
| AC Output (Inverter) |
Rated Output Voltage | 100~240V(Customized according to different countries and regions) |
| Output Frequency | 60Hz/50Hz(Depends on factory set according to different countries and regions) | |
| Output Voltage Type | Modified Pure Sine Wave | |
| Output Socket | Customized according to different countries and regions | |
| Output Power | 120W | |
| Output Peak Power | 200W (2second) | |
| Efficiency | >90% at 70% of full loading | |
| Input (Recharge) |
AC Charge | AC-DC Adaptor(CC/CV) 30W (DC7.9x5.5mm) |
| PV/Solar Charge | MPPT, Input voltage range：14~40V, 60W(DC7.9x5.5mm) | |
| Car Charger | Car input voltage range：13-40V, Charge current:10A max (DC7.9x5.5mm) | |
| Display | Battery Status | Capacity by 5cases @ 20% each，flashing while charging |
| Working Status | Discharging, Recharging, | |
| Error Code | E01-E99, Refer to the user manual | |
| Working Condition | Charge Temperature | 0℃～45℃ |
| Discharge Temperature | -10℃～60℃ | |
| Operation Humidity | 10%～90% | |
| LED Lighting | NA | NA |
| Heat Dissipation | Air cooling, Aluminum housing. | |
| IP rate | To prevent spraying water from a vertical direction angle less than 60 degrees. | |
| Self-consumption | <50uA(turn-off) | |
| Dimensions & Weight | 202*67*207mm, 3kg. | |
| Certificates | UL, PSE,CE ,FCC, RoHS,UN38.3 | |
When/Where We Use This Portable Power Solar Generator:
-
Outdoor power supply for lighting, cooking and entertainment in any camping, road trip.
-
Backup power supply for emergency needs, such as power outages, hurricanes, earthquakes.
-
Good as high capacity power source of mobile phone,tablet,digital camera,wifi router,CPAP,drone,lamp,fan,TV,Refrigerator,laptop,etc.
