Cera100U Lithium Battery Pack Box
Cera100U Front Access 48V100Ah Lithium Battery Pack Box
Features
- High energy density: more energy with less weight and footprint.
- High discharge/charge currents (short charge period)
- Long battery life (up to three times the battery life of a conventional battery)
- High efficiency between charging and discharging
- Fast charging and slow discharging
- Anti-theft solution and RMS integration featured (remote management system)
- Higher continual power availability
- Other functions (optional): Anti Thief / LCD / Dry Contact
- It ensures high safety, high energy density and good cycling life (2000 to 3000 cycles@80%DOD,
35℃,70%EOL).
- Customized dimensions fit in existing standard cabinets for easier replacement.
- Point of grounding connection
- Lifespan 8 to 10 years
Cera100U Front Access 48V100Ah Lithium Battery Pack Box
Product Parameters(Cera100U):
| Model | Cera 100U |
| Rated voltage | 48V |
| Rated capacity | 100Ah |
| Interface connector | RS485+RS232*2 |
| Switch type | DIP |
| Cell type | Lithium-ion Ferrous Phosphate(LFP) |
| Max charging voltage | 54.75V |
| Max charging current | 20A |
| Discharge cut-off voltage | 37.5V |
| Max discharge current | 100A |
| Cycling lifespan | ≥1500（80% DOD） |
| Display | LCD |
| Charging temperature | 0 ℃ to 45 ℃ |
| Discharging temperature | -20 ℃ to 60℃ |
| Heat dissipation | Smart air cooling |
| Dimension | L442*W410*H221mm(Front access) |
| Weight | 41kg |
| Application | EPS Backup Power Supply |
| Communication base station | |
| Wind/Solar energy storage | |
| Warranty | 18months |
Cera100U Front Access 48V100Ah Lithium Battery Pack Box
Applications
1. Golf trolleys, Golf carts,
2. UPS backup
3. Fire alarm and security systems
4. Telecommunication equipment
5. Electric equipment and telemeter equipment
6. Light equipment, dc 48v led lights
7. Wireless lawn movers vacuum cleaner and washing machine
8. Toys and consumer electronics
9. Solar systems 48V
10.Portable power tools measuring and medical equipment
11.Portable video camera portable personal computer
12.Garden lighting
13.Sound systems
